CURTAIN WALLS & DIVIDERS

Separate and maximize your usable space with a retractable barrier for confining paint overspray, dirt, dust, grinding sparks and contaminants, and controlling cold loss. Curtain walls are perfect for auto body, industrial, woodworking and many other applications. All materials meet NFPA 701 for fire retardancy.

Global Finishing Solutions curtain walls can be used for a variety of applications including:

Aluminum repairSanding & grinding
Auto body prep areasWarehouse separation
Dust containmentWash bays
Estimating baysWelding
Limited paint enclosuresWoodworking


Features

Chain Weighted Hem

Heavy-duty, 3/16 inch galvanized chain inserted into the 4 inch bottom pocket to stabilize the curtain against drafts.

Velcro Attachments

Two-inch velcro side attachments easily seal and attach both sides of curtains to multiple curtains. Available in standard two-foot swatches, full length or custom.

Hooks & Grommets

Made for easy sliding and folding of the curtain, two-wheel steel roller hooks are available for large curtain systems.

#2 brass toothed grommets are spaced every 12 inches on center of the curtains to hang securely on the roller hooks.

Electronically Welded Seams

Interior seams are electronically welded with RF bar sealers for an extra tough resistance to tears. Outer hems are sewn with a heavy-duty, double-lock stitched nylon thread.

Work-View Window

20-mil, flame resistant and double polished PVC window for a clear view of workers and operations. Meets CFM and NFPA 701 standards.

Roller Track System

Heavy-duty, 16-gauge roller track system which modularly connects track lengths to your desired shape and length. Available in Suspended Mounts – Threaded Rod or Beam to Chain, Ceiling Mount, Floor Mount and Beam Flange Mount.

Steel-Scrim™ Laminate Vinyl​

Global Finishing Solutions curtains feature our proprietary, tri-lateral polyester scrim design, Steel-Scrim™ Vinyl, which is 84 percent stronger than standard laminate vinyl. Built to last, this material is the toughest PVC vinyl on the market with more than 406 pounds per square inch of tensile strength in its construction.

Steel Scrim Vinyl Curtians


Accessories & options

Weld-View Window: 14-mil, PVC weld-view window blocks harmful UV Rays from welding while allowing view of workers. Meets CFM and NFPA 701 standards.
Vinyl Floor Sweep: Sew-in or velcro option. Seals bottom 1-inch gap to seal off dirt, dust or contaminants.
Adhesive Velcro: Attaches any curtain to a brick, metal, concrete or wood wall or door opening.
Floor Mount D-Rings: Included with strap and buckle. Securely fastens your curtain system when heavy updrafts are a problem.

Code Compliance

GFS guarantees that our products meet or exceed all of the applicable codes related to the equipment. Our engineers regularly follow and contribute to the advancement of codes and standards that affect the industries that we work in. One of our engineers currently serves on the NFPA Technical Committee on Finishing Processes, a key standard in the finishing industry.

OSHA Logo
NFPA Logo
ETL C logo
EPA logo
ICC Logo
Want to learn more about curtain walls and dividers?
Let us know your product requirements, and we will put you in touch with a distributor in your area.
