INDUSTRIAL pretreatment washer

Clean and Prepare Prior to Powder and Liquid Coatings

Industrial Wash booth

INDUSTRIAL pretreatment washer

Global Finishing Solutions® (GFS) Industrial Pretreatment Washers are used for cleaning metal and plastic substrates prior to liquid or powder coating, as well as before and after machining or forming components. Industrial Pretreatment Washers provide a highly efficient environment for washing processes and are often designed with separate housing sections to accommodate multiple pretreatment stages.


Precise Engineering

Precision engineered and manufactured of heavy-duty materials, GFS Industrial Pretreatment Washers are built to last. The tanks on GFS Pretreatment Washers are double-welded — both on the inside and outside — preventing leaks.

Easy Installation

The modular design of GFS Pretreatment Washers allows for easier, quicker installation, so you can begin using your equipment sooner. Many of our Pretreatment Washers are preassembled at our manufacturing facility in Osseo, Wisconsin, to ensure proper fit and function, which also shortens installation time.


GFS is experienced at designing and building high-quality washers that are custom engineered to meet your business’ needs. GFS Industrial Pretreatment Washers can be designed as a spray or immersion environment — or as a combination of both.

Multi-Stage Washers

The number of stages and design of the Industrial Pretreatment Washer is dependent upon the complexity and finish specifications of the parts. A typical multi-stage washer includes a chemical cleaning stage, followed by water and seal rinse stages. Complex multi-stage washers may also include phosphate stages, additional rinse stages, and reverse osmosis or surfactant final rinse stages.

Adjustable Nozzles

GFS Pretreatment Washers feature clip-on nozzles, which can be easily removed for cleaning, allowing for hassle-free maintenance. Since each nozzle can be adjusted, you can precisely aim it at the desired part or product in the washer.


MORE Features

Stainless or mild steel
Overflow gutters on all stages
Dual stainless steel filter screens with bottom sludge dam
Gas-fired immersion heating equipment
Removable access covers
Sloped tanks to sump drain for easy cleanout
Stainless or mild steel
Drain decks sloped (70/30 with a 2-inch center dam)
Bulkhead access doors in drain stages
Entrance and exit exhaust vestibules
Silhouettes between all spray sections
Bolted construction
CPVC schedule 80 header piping with quick, overhead disconnects
CPVC schedule 80 risers with quick disconnects
Drains, overflows and counter-flow piping (schedule 80 CPVC)
Rapid fill bypass on all stages
Vertical pumps
Thermometers on heated stages
Pressure gauges on all stages
UL-listed, PLC-based control panel
Electronic solution-level controls on all stages


The following options can be added to a GFS Industrial Pretreatment Washer:

Stainless steel grating in solution tanks
Insulated tanks with 18-gauge, stainless steel panels
Manual solution level controls
Particle filtration system
Oil separation systems
Conveyor shrouds in spray and drain stages
Tank cleanout marine doors
Blow-off units or dry-off ovens for drying parts

Code Compliance

GFS guarantees that our products meet or exceed all of the applicable codes related to the equipment. Our engineers regularly follow and contribute to the advancement of codes and standards that affect the industries that we work in. One of our engineers currently serves on the NFPA Technical Committee on Finishing Processes, a key standard in the finishing industry.

ETL C logo
EPA logo
ICC Logo
Want to learn more about pretreatment washers?
Let us know your product requirements, and we will put you in touch with a distributor in your area.
