Typically used in batch and low/medium production applications, this dust collection booth features an open-face design, 3-stage filtration system and a high-capacity, low-noise recirculation fan for maintaining a high-performance application environment.
GFS Sanding Booths are constructed with single-skin, 18-gauge, G-90 galvanized steel.
Easy Filter Replacement
Each Sanding Booth comes complete with a full set of filters. Installing and replacing filters is easy with the grid system. An included manometer indicates when filters need to be replaced.
Pre-punched booth panels and nut-and-bolt assembly on Sanding Booths takes the guesswork out of installation and provides more structural integrity.
Each GFS Sanding Booth features energy-efficient, inside access, T8 light fixture(s).
Three-Stage Filtration System
Featured in GFS’ Sanding Booths, the three-stage filtration system is highly effective at capturing high volumes of dust (with up to 99.9 percent filter efficiency at 5 microns). The first stage includes roll media filtration, the second stage includes panel filters and the final stage includes six-pocket bag filters.
Fans & Motors
GFS Sanding Booths include a heavy-duty, high-capacity, low-noise plug fan (rated at 1.5 in. static pressure) that recirculates clean air.
GFS Sanding Booths can be customized to meet your unique specifications. The following options can be added to a Sanding Booth:
Pre-coated white panels
Standard control panel
GFS guarantees that our products meet or exceed all of the applicable codes related to the equipment. Our engineers regularly follow and contribute to the advancement of codes and standards that affect the industries that we work in. One of our engineers currently serves on the NFPA Technical Committee on Finishing Processes, a key standard in the finishing industry.
