EnviroTect Water Wash Paint Booth

For Use on the Most Difficult Coating Materials

Description

EnviroTect Water Wash Spray Booths from Global Finishing Solutions® (GFS) perform efficiently with even the most difficult coating materials. Straight-line, non-turbulent airflow through the spray curtain improves paint particle capture and cleaning action, while reducing energy consumption.

Process

Most Commonly Used For

COLLECTION

EnviroTect Water Wash Paint Booth Product Info

The following features come standard on EnviroTect Water Wash Spray Booths:

ConstructionEnviroTect Water Wash Spray Booths are constructed with single-skin, 18-gauge, G-90 galvanized steel. Pre-punched booth panels and nut-and-bolt assembly take the guesswork out of installing the booth, in addition to providing more structural integrity.
LightingGFS Water Wash Paint Booths feature integrated four-tube, inside-access light fixtures. All GFS light fixtures are ETL and ETL-C listed and come complete with energy-efficient LED lamps.
Fans & MotorsEnviroTect Water Wash Paint Booths include a tube axial exhaust fan(s) and a three-phase, TEFC, dual-voltage motor(s) with variable pitch pulley.
Washer AssemblyEnviroTect Water Wash Paint Booths feature a welded washer assembly, constructed of 12- or 14-gauge galvanized steel.
Air & Liquid NozzlesAir and liquid nozzles are spaced according to production and air volume requirements. Nozzles are made of 326 stainless steel and feature 150 GPM and 4 psi.
Easy MaintenanceInterior surfaces are wetted to eliminate paint overspray buildup, which reduces booth cleaning and captures the paint in the eliminator for removal.
Air enters the booth through the built-in trough, which provides an initial wetting action on the paint particles.
Air flows through a restricted flow passage in the booth to form a column of straight-line, non-turbulent airflow.
With accelerating velocity, air moves through one or more continuous, solid curtains of washing liquid, where contaminant particles in the air are contacted and wetted by the liquid.
The resulting commingled air and liquid are discharged into an eliminator chamber. This reduces the air velocity and allows the wetted contaminants to drop out of the air stream.
Designed for standard industrial applications
Rated as passing less than 5 grains solids per 1,000 CFM*
Features reduced energy requirements

*Based on handling 5,000 CFM of contaminated air per air/liquid nozzle and using chemically compounded water as the wash medium

High-efficiency spray booth designed for heavy industrial painting
Rated as passing less than 3 grains solids per 1,000 CFM*

*Based on handling 5,000 CFM of contaminated air per air/liquid nozzle and using chemically compounded water as the wash medium

GFS products are designed and manufactured to meet the applicable requirements of various industry-recognized codes and standards.

  • Reference NFPA 33 and Chapter 24 of the International Fire Code (IFC) for spray applications using flammable and combustible materials
  • Reference NFPA 86 and Chapter 30 of the IFC for curing and drying applications
  • Many components and product lines are ETL and ETL-C listed. The ETL or ETL-C mark is proof of compliance with North American safety standards, including UL, NFPA, OSHA and more
  • A UL or CUL listing verifies that Underwriters Laboratories has tested GFS’ product and determined that it meets their stringent safety and performance requirements


Please be aware that local requirements may vary from national codes. GFS recommends consulting with your local authority before purchasing paint booths or other finishing equipment.

GFS engineers regularly contribute to the advancement of codes and standards that affect the industries that we work in. Several of our engineers serve on various NFPA Technical Committees responsible for key finishing industry standards.

Why Water Wash?

GFS Water Wash Spray Booths provide an extremely efficient means for removing paint particles from the exhausted air, and are the most acceptable type of paint booth for all health, fire and building codes. Water Wash Booths are ideal when using large quantities of coatings, usually more than five gallons per day per square foot of face area.

Want to learn more about our EnviroTect Water Wash Paint Booths?

Let us know your product requirements, and we will put you in touch with a distributor in your area.
