Ultra® XL Paint Booth

Automotive Spray Booth for Oversized Vehicles


With a 12-foot-high ceiling designed for painting Sprinter vans, commercial vehicles and full-size pickup trucks, the Ultra XL Paint Booth from Global Finishing Solutions® (GFS) brings the performance you expect from the Ultra Paint Booth line to an extended range of vehicle sizes and heights. With premium brightness, contamination control, energy efficiency and single- or dual-skin construction, the Ultra XL sprinter van paint booth is the perfect solution for oversized paint jobs.


Most Commonly Used For


Ultra® XL Paint Booth Product Info


Exclusive to GFS, the Controlled Airflow Ceiling on the Ultra XL truck booth maximizes the effectiveness of downdraft airflow and increases the booth’s overall spray zone with a full-width ceiling plenum. The main airflow zone in the Controlled Airflow Ceiling creates a protective envelope of air around the vehicle, while secondary airflow zones protect booth walls from overspray and keep contaminants out of the paint job.

Learn More About Airflow

LightingUltra XL truck booths feature four-tube sidewall light fixtures and premium angled ceiling light fixtures, integrated into the Controlled Airflow Ceiling and located directly above the vehicle for optimal illumination. Light fixtures are ETL and ETL-C listed, and come complete with T8 ballasts and energy-efficient LED lamps.
DoorsA four-wing, dual-skin product door — with four observation windows — and one personnel door come standard on the pre-engineered Ultra XL Paint Booth. Doors feature heavy-duty hinges for long-lasting performance.

GFS’ Ultra XL truck paint booth offers the flexibility of choosing between two heat units – the GUL2000 or BT1200 heat system. Both heaters include dual VFDs and automatic pressure control.

Learn More

Energy SavingsShops can save up to 60 percent in electricity and 75 percent in fuel costs with economy mode, which automatically ramps the Ultra XL Paint Booth down and runs on idle when the booth is not in use. Providing further energy savings, SmartFlash on optional LOGIC 3 or LOGIC 4 control panels allows up to 90 percent of the air to be recirculated during flash mode.
ConstructionManufactured at our U.S. facility, Ultra XL oversized paint booths are made with dual-skin, insulated, galvanized steel panels that are coated on both sides with a white, baked-on polyester topcoat, creating a rust-resistant cabin. Vertical wall panels reduce the number of joints and seams in the cabin’s construction, leaving you with a stronger, longer-lasting booth with a smooth fit and finish.
Single-row exhaust pit
Choice of single- or dual-skin construction
Four-wing, dual-skin product door
One personnel door
Choice of GUL2000 or BT1200 heat system

GFS paint booths can be customized to meet your unique specifications. The following options can be added to the Ultra XL Paint Booth:

AdvanceCure® Accelerated Airflow System
Two- or three-row exhaust pit upgrade
Drive-thru configuration
LOGIC 3 or LOGIC 4 controls
Additional sidewall light fixtures
Raised basement (adds 13 inches to the overall height of the paint booth)
Six-tube, T8 LED light fixtures
Heat SystemBTRC or GUL
Internal Dimensions (W x H x L)14′ x 12′ x 27′
External Dimensions (W x H x L)14′ 5″ x 14′ x 27′ 5″
6-Tube Ceiling Light Fixtures8
6-Tube Sidewall Light Fixtures6
Dual-Row Pit Length24′
Heat SystemBTRC or GUL
Internal Dimensions (W x H x L)14′ x 12′ x 30′
External Dimensions (W x H x L)14′ 5″ x 14′ x 30′ 5″
6-Tube Ceiling Light Fixtures10
6-Tube Sidewall Light Fixtures6
Dual-Row Pit Length27′

GFS guarantees that our products meet or exceed all of the applicable codes related to the equipment. Our engineers regularly follow and contribute to the advancement of codes and standards that affect the industries in which we work. One of our engineers serves on the NFPA Technical Committee on Finishing Processes, a key standard in the finishing industry.

OSHA – Occupational Safety and Health Administration
NFPA – National Fire Protection Association
ETL – Electrical Testing Labs
EPA – Environmental Protection Agency
ICC – International Code Council

Ultra® Paint Booth Line

Since 1999, GFS’ proven and sought-after Ultra Paint Booth line has provided automotive body shops and collision repair centers with high-performance finishing environments for painting vehicles and parts.

The Ultra Paint Booth line features premium lighting, efficiency-boosting controls, excellent airflow and advanced contamination control, enabling shops to achieve high-quality paint finishes in a bright, clean and ecologically friendly environment. GFS continually improves its products and components, guaranteeing quality and consistent results throughout the Ultra line.
