The Excel® Workstation from Global Finishing Solutions® (GFS) provides a controlled environment for sanding, priming and limited painting. The workstation meets the requirements of the EPA’s 6H Paint Rule (40CFR63 Subpart HHHHHH). When priming and painting, the amount of material sprayed shall not exceed one gallon in an eight-hour period.
| Lighting | GFS Excel Workstations come complete with four-tube ceiling light fixtures. The light fixtures are ETL and ETL-C listed, with energy-efficient LED lamps. |
| Airflow | GFS Excel Workstations are available in semi-downdraft airflow. Air is introduced to the booth through the ceiling in the first 25 to 30 percent of the workstation. It’s then pulled through the working chamber, over the vehicle and into the filtered exhaust chamber at the rear of the workstation. |
| Curtain Walls | With curtain walls, GFS Excel Workstations provide a flexible working space. The retractable barrier confines dirt, dust and contaminants, while controlling heat loss. All materials meet NFPA 701 for fire retardancy. |
| Construction | Constructed of standard panel sizes, GFS Excel Workstations are available in multiple length, width and height options to suit any shop layout. The structure can be freestanding, with structural steel supports, or suspended from your shop’s ceiling. |
| White, pre-coated galvanized steel |
| Fans and motors |
The following options can be added to GFS Excel Workstations:
| Six-tube, T8, LED light fixtures |
| Exhaust ductwork |
| Dimensions | Ceiling Lights | Intake Fans |
| 12′ x 9′ x 24′ | 5 | 1 |
| 12′ x 9′ x 27′ | 6 | 1 |
| 12′ x 9′ x 30′ | 7 | 1 |
| 12′ x 12′ x 24′ | 5 | 1 |
| 12′ x 12′ x 27′ | 6 | 1 |
| 12′ x 12′ x 30′ | 7 | 1 |
| 24′ x 9′ x 24′ | 10 | 2 |
| 24′ x 12′ x 24′ | 10 | 2 |
GFS products are designed and manufactured to meet the applicable requirements of various industry-recognized codes and standards.
Please be aware that local requirements may vary from national codes. GFS recommends consulting with your local authority before purchasing paint booths or other finishing equipment.
GFS engineers regularly contribute to the advancement of codes and standards that affect the industries that we work in. Several of our engineers serve on various NFPA Technical Committees responsible for key finishing industry standards.
