Ultra® XD CTOF

Deluxe, Dual-Skin Automotive Prep Environment

UltraXD CTOF

ULTRA XD CTOF

premium closed-top open-front booth

A versatile, end-to-end finishing environment, the Ultra XD Closed-Top Open-Front (CTOF) Booth from Global Finishing Solutions® (GFS) allows for vehicles to be filled, primed, sealed, painted and cured in one location.

The Ultra XD CTOF Booth is an ideal complement to our top-of-the-line paint booths. With dual-skin walls and superior construction, airflow and lighting, the Ultra XD CTOF is a premium environment for prepping and painting.

Features

Airflow

Ultra XD CTOF Booths come standard with GFS’ High-Performance Airflow Ceiling in downdraft or semi-downdraft airflow models. The full-filtered ceiling provides excellent air filtration and contamination control.

Lighting

Ultra XD CTOF booths feature four-tube hip-style lights. All GFS light fixtures are ETL and ETL-C listed, and come complete with T8 ballasts and color-corrected tubes.

Dual-Skin Insulated Panels

Pre-coated, dual-skin insulated panels on Ultra XD CTOF Booths provide a smooth fit and finish with no exposed wires or cables. Insulated panels cut down on noise and reduce ambient heat outside of the booth, while keeping heated air inside the cabin.

Heater

Highly versatile, the Ultra XD CTOF Booth has an option of GFS’ BT1200 heat unit or exclusive roof-integrated SpaceSaver heat system. The BT1200 heater can be placed on the side or rear of a paint booth, and is available in forced-dry models (BTFD). Ideal for space-conscious businesses, the SpaceSaver heater effectively compacts a high-efficiency heat system into the same area as the paint booth plenum.

Controls

Standard on GFS’ Ultra XD CTOF, the Engage control panel features a simplified, easy-to-use touch screen interface with enhancements such as improved temperature and pressure control and alarm tracking for better, more reliable booth performance.

Construction

Manufactured at our U.S. facility, Ultra XD CTOF Booths are made with dual-skin insulated, galvanized steel panels that are coated on both sides with a white, baked-on polyester topcoat, creating a rust-resistant cabin. Vertical wall panels reduce the number of joints and seams in the cabin’s construction, leaving you with a stronger, longer-lasting booth with a smooth fit and finish.



More Features

Self-supporting structure design
Solid back wall panels
Front curtain(s)
Divider curtain(s) for dual-bay models
Personnel door with observation window


BOOTH Options

All of GFS’ booths can be customized to meet your unique specifications. The following options can be added to an Ultra XD CTOF Booth:
Two- or three-row pit (downdraft only)
AdvanceCure Blade or Nozzle
Drive-thru configuration (four-wing not available on semi-downdraft models)
Six-tube light fixtures
LED lamps or light reflectors
Four- or six-tube corner or sidewall light fixtures
Three- or four-wing doors
Control panel upgrade


BOOTH SPECS

All Ultra XD CTOF Booths come in Downdraft OR Semi-Downdraft models:

Heat SystemBTFD or SpaceSaver
Internal Dimensions (W x H x L)14′ x 9′ x 24′
External Dimensions (W x H x L)14′ 8″ x 11′ x 24′ 8″
No. of Hip-Lights8
Single Row Pit21′
Heat SystemBTFD or SpaceSaver
Internal Dimensions (W x H x L)14′ x 9′ x 27′
External Dimensions (W x H x L)14′ 8″ x 11′ x 27′ 8″
No. of Hip-Lights8
Single Row Pit24′
Heat SystemBTFD or SpaceSaver
Internal Dimensions (W x H x L)24′ x 9′ x 24′
External Dimensions (W x H x L)24′ 8″ x 11′ x 24′ 8″
No. of Hip-Lights12
Single Row Pit21′ (2)
Heat SystemBTFD or SpaceSaver
Internal Dimensions (W x H x L)24′ x 9′ x 27′
External Dimensions (W x H x L)24′ 8″ x 11′ x 27′ 8″
No. of Hip-Lights16
Single Row Pit24′ (2)

*Floor-mounted and SpaceSaver air heater dimensions are not included in the outside dimensions.

Code Compliance

GFS guarantees that our products meet or exceed all of the applicable codes related to the equipment. Our engineers regularly follow and contribute to the advancement of codes and standards that affect the industries that we work in. One of our engineers currently serves on the NFPA Technical Committee on Finishing Processes, a key standard in the finishing industry.

OSHA Logo
NFPA Logo
ETL C logo
EPA logo
ICC Logo
